EN818-2
- Package: in carton or polybag
- Surface: GALV. OR POWDER PLASTIFIED
- Material: Alloy Steel
- Standard LIFTING
573.jpg "EN818-2")
921.jpg "EN818-2")
| SIZE(mm) | Inside length(mm) | Inside width(mm) | Weight(kg/m) | Working Load(KN) | Proof Load(KN) | Break Load(KN) |
| 6 | 18 | 7.8 | 0.8 | 11.2 | 28.3 | 45.2 |
| 7 | 21 | 9.1 | 1.1 | 15 | 38.5 | 61.6 |
| 8 | 24 | 10.4 | 1.4 | 20 | 60.3 | 80.4 |
| 10 | 30 | 13 | 2.2 | 31.5 | 78.5 | 126 |
| 13 | 39 | 16.9 | 3.8 | 53 | 133 | 212 |
| 16 | 48 | 20.8 | 5.7 | 80 | 201 | 322 |
| 18 | 54 | 23.4 | 7.3 | 100 | 254 | 407 |
| 20 | 60 | 26 | 9.00 | 125 | 314 | 503 |
| 22 | 66 | 28.6 | 10.9 | 150 | 380 | 608 |
| 26 | 78 | 33.8 | 15.2 | 212 | 531 | 849 |
